Why the DP001 Sets the Standard
| Feature / Specification | Conventional Single Gauges | Typical 52mm CAN Displays | High-End Multi-Displays | PulseWorks DP001 |
|---|---|---|---|---|
| Typical System Cost | €350 – €500+ (Stack of 3–4) | €380 – €460+ | €330 – €400+ (With looms) | €296 (Includes 1m Loom) |
| Display Technology | Stepper / Analog / Segment | Standard Round LCD | Small Rectangular OLED | 1.75" Full-Circle AMOLED Touch |
| Display Resolution | Fixed needles / ~128px | ~240 × 240 | Low-res / Segmented | 466 × 466 (326+ PPI Retina) |
| True Black (Zero Bleed) | No (Backlight glow) | No (LCD gray glow) | Yes | Yes (Pure infinite contrast) |
| Independent Analog Inputs | 1 per gauge | 0 (CAN Only) | 4 to 6 Channels | 8 Channels (16-Bit Dual ADC) |
| 1m Pre-Crimped Harness | Separate per gauge | Basic 4-pin plug | Extra cost accessory | Included Free in the Box |
| CAN I/O Expander Mode (TX) | ❌ No | ❌ No | ❌ No | ✅ Included (Broadcast to ECU) |
| Virtual Touch CAN Keypad | ❌ No | ❌ No | ❌ No | ✅ Included (4/6/8-button switch panel) |
| Direct Flex Fuel Pulse Decode | External box needed | ECU only | Varies | ✅ Included (Ethanol % + Fuel Temp) |
| 6-Axis IMU (G-Force & Gyro) | ❌ No | ❌ No | Extra module needed | ✅ Included (G-Meter + Inclinometer) |
| Engine Protection System | Static Limit Buzzer | Static Thresholds | Basic Thresholds | ✅ 2D RPM-Gated Curves + Touch Snooze + Audio feedback |
| On-Board MicroSD Logging | ❌ No | ❌ No (Phone app) | Basic PC USB log | ✅ MegaLogViewer (.MSL) & SavvyCAN |
| DBC File Import Wizard | Manual / None | Manual / Web | Manual / Web | ✅ In-Browser Drag-and-Drop DBC |
| Custom UI Design | Fixed faceplates | Web interface | Web interface | ✅ Live WYSIWYG Gauge Studio |
Full Technical Specifications (Click to expand)
| Category | Specification |
|---|---|
| Form Factor | Standard 52mm (2-1/16") round automotive instrument diameter |
| Display | 1.75" High-Brightness Full-Circle AMOLED Touchscreen |
| Resolution & Pixel Density | 466 × 466 pixels (326+ PPI Retina display) |
| Touch Controller | High-sensitivity capacitive touch controller (100 Hz polling) |
| Processor & Memory | Espressif ESP32-S3 Dual-Core LX7 @ 240 MHz, 8MB Octal-SPI PSRAM, 16MB Flash |
| Analog Channels | 8x Independent 16-Bit Analog Inputs (Dual ADS1115 ADCs) |
| Analog Input Modes | Hardware selectable 0–5V linear or NTC resistance with pull-ups |
| Calibration Precision | Custom 10-point piecewise linear calibration curves per channel |
| Digital Inputs | Hardware interrupt pulse capture for Continental / GM Flex Fuel sensors or auto dimming for headlight / night driving |
| CAN Bus Interface | High-Speed CAN 2.0B (100, 125, 250, 500, 800, 1000 kbps) with auto-recovery |
| CAN Bus Termination | Onboard switch for 120 Ohm termination |
| CAN Transmission (TX) | Configurable CAN broadcast / expander mode (10–50 Hz) |
| Inertial Measurement | 6-Axis IMU (3-axis Gyroscope + 3-axis Accelerometer) with sensor fusion |
| Data Logging | MicroSD Card slot supporting FAT32 (CSV, MSL, and SavvyCAN formats) |
| Wireless Connectivity | 2.4 GHz Wi-Fi (SoftAP & Station modes) with secure encrypted OTA updates |
| Operating Voltage | 9V – 18V DC automotive electrical systems |
| Enclosure Material | High-temperature, UV-resistant ASA Carbon Fiber (ASA-CF) composite |
| Mounting Mechanism | Rattle-free crush-rib body with precision rear-locking anti-rotation C-clip |
Engineered for Motorsport. Built for Precision.
Why settle for a slow, single-purpose gauge when you can have a complete 8-channel telemetry hub, CAN expander, and data logger in a standard 52mm form factor?
High-Speed Display & Dual-Core Power
1.75" True Round AMOLED (466×466 px, 326 PPI): Crisp, sunlight-readable clarity with infinite contrast and true pitch blacks. No visible backlight glow inside dark gauge pods.
Deterministic Dual-Core Processing: Powered by a 240 MHz dual-core ESP32-S3 with 8MB high-speed PSRAM. Core 0 handles real-time 1000 kbps CAN decoding and 200 Hz analog acquisition; Core 1 drives a buttery-smooth 60 FPS LVGL render loop. Zero missed spikes, zero display lag.
Responsive Capacitive Touch: Effortlessly swipe through multi-gauge dashboards, silence alarms with a single tap, or configure sensor slots on the fly without touching a laptop.
8-Channel Data Acquisition & CAN I/O Expander
8 Independent 16-Bit Analog Inputs: Monitor oil pressure, fuel pressure, exhaust gas temps (EGT), and fluid temperatures without needing an aftermarket ECU.
CAN I/O Expander Mode (CAN TX): Ran out of analog inputs on your standalone ECU? The DP001 transmits all 8 analog channels, Flex Fuel data, and IMU telemetry over CAN directly to your Haltech, Ecumaster, Link, or MaxxECU—saving you hundreds on a dedicated expansion box.
Direct Flex Fuel Decoding: Built-in hardware interrupt capture decodes Continental/GM flex fuel sensors directly on the board (50–150 Hz ethanol %, 1–5ms fuel temp).
Zero-Install Wireless Web Interface
No Software, No Drivers, No USB Cables: Connect directly to the DP001’s built-in Wi-Fi from your smartphone, tablet, or laptop.
Drag-and-Drop DBC Parser: Import custom .dbc CAN database files directly in your web browser. Select your signals and map them to display widgets in seconds.
WYSIWYG Gauge Studio: Design bespoke gauge layouts with custom dial backgrounds, needle styles, radial sweep arcs, and digital readouts with built-in client-side image optimization.
Dynamic Engine Protection & MicroSD Logging
2D RPM-Gated Protection Curves: Traditional static oil pressure alarms trigger false warnings at idle. The DP001 evaluates 2D threshold curves (e.g. 1.2 bar @ 900 RPM, 3.5 bar @ 3500 RPM, 5.0 bar @ 6500 RPM) for true race-grade engine protection.
MicroSD Telemetry & Raw CAN Logging: Automatically records decoded sensor channels in EFI Analytics MegaLogViewer (.MSL / CSV) format or raw bus traffic in SavvyCAN format with automatic engine-crank triggers (>400 RPM).
Integrated 6-Axis IMU: Live lateral G, longitudinal braking/acceleration G-force, yaw rate, and a dedicated 4x4 Offroad Inclinometer screen with 1-touch tare zero calibration.
Turn Your Gauge into a Touchscreen CAN Keypad
Interactive Virtual CAN Switch Panel
Eliminate the clutter and expense of bulky external button boxes. The DP001 features an integrated Virtual CAN Keypad engine capable of emulating industry-standard CAN switchboards (including Ecumaster 0x660 and Haltech 0x360 protocols).
Multiple Layouts: Choose between 4-button quadrant, 6-button grid, or 8-button radial switch panels.
Versatile Button Actions: Momentary (active while held), Latching Toggle (tap for ON/OFF), or 3-to-4 stage cycling (e.g., Boost Levels 1-2-3-4).
Direct ECU Control: Trigger launch control, arm anti-lag, cycle boost target tables, override electric water/fan pumps, or switch ECU calibrations right from the touchscreen.
2D Engine Protection: Alarms That Actually Save Engines
Intelligent 2D Gated Warning Architecture
A static warning light at 2.0 bar will either scream at you during a hot idle or fail to warn you when oil pressure drops dangerously low at 7,500 RPM under boost.
The DP001 solves this with 2D dynamic piecewise curve interpolation:
Define custom multi-point curves (e.g. Minimum Oil Pressure vs. RPM).
Set debounce timers and hysteresis thresholds to prevent erratic false triggers during gear changes.
Choose your own audio feedback from built-in chimes to your own audio files.
Two-Tier Warning Stages: Tier 1 pulsing peripheral warning beacon and warning audio (customize strobe rate, color and audio) progressing to a Tier 2 full-screen critical alarm takeover with one-touch snooze silencing (customizable audio).
MicroSD Data Logging & Diagnostics
Built-In Telemetry Flight Recorder
The DP001 features on-board MicroSD data logging designed for high-speed continuous recording—capturing every sensor sample and CAN packet with zero frame drops or display lag.
MegaLogViewer Compatible (.MSL / CSV): Log all active CAN parameters, 8 analog sensors, Flex Fuel data, and 6-axis G-forces. Open and overlay your logs directly in EFI Analytics MegaLogViewer.
Raw CAN Sniffing (SavvyCAN): Capture raw bus traffic for reverse engineering vehicle networks and diagnostic troubleshooting.
Auto-Crank Trigger: Automatically engages logging the moment engine speed exceeds 400 RPM—never forget to hit "record" before a session.
Integrated OBD-II Diagnostics: Read and clear Diagnostic Trouble Codes (DTCs) with standard Mode 03, 07, and 04 support.
-
Most 52mm gauges on the market are single-purpose displays: they either read basic CAN parameters from an ECU or display a single analog sensor.
The DP001 is a full-featured motorsport telemetry and control node. It combines an ultra-high-resolution 466×466 AMOLED screen with 8 independent 16-bit analog inputs, a 6-axis G-meter, MicroSD data logging, direct Flex Fuel frequency decoding, and a CAN I/O Expander that can transmit your sensors back to your ECU.
-
Yes! Because the DP001 features 8 independent 16-bit analog inputs with custom 10-point calibration tables, you can run oil pressure, fuel pressure, oil temperature, water temperature, boost, and EGT sensors directly into the gauge without needing any ECU. It also connects directly to standard factory OBD-II ports on 2008+ vehicles.
-
Standalone ECUs (like Haltech Elite, Link G4X, or Ecumaster EMU Black) frequently run out of physical analog input pins when you add fuel pressure, oil pressure, ethanol content, and differential temps. Dedicated CAN expansion boxes typically cost €250 to €400.
The DP001 reads your sensors directly and broadcasts them over CAN bus to your ECU using pre-configured Haltech, Ecumaster, or custom protocols, acting as an 8-channel expansion module and display in one unit.
-
No. The DP001 hosts its own web application over Wi-Fi. Simply connect to the gauge from your smartphone, tablet, or laptop browser. You can drag and drop .dbc CAN files, arrange widgets in the visual Gauge Studio, convert custom dial images, and tweak alarm thresholds—with zero software or app store downloads required.
-
Every DP001 includes a complete 1-meter 16-pin harness with pre-crimped automotive-grade wiring and labeled flying leads right in the box. You don't need specialized crimp tools or loose connector pins; simply route the harness through your dash and splice into your power, CAN, and sensors.
What's in the Box?
1× PulseWorks DP001 52mm AMOLED Telemetry Display
1× 1-Meter Pre-Crimped 16-Pin Automotive Wiring Loom:
Power (12V Switched Ignition & Ground)
High-Speed CAN Bus (CAN-H, CAN-L)
Headlight Illumination Dimming Trigger (12V)
8× Color-coded flying leads for Analog Inputs & Flex Fuel signal
1× 5V Sensor Output
1x High-Speed connection for expansion modules (RX, TX)
1× Heavy-Duty Anti-Rotation Rear Mounting C-Clip
1× Quick-Start Card with QR code to Web Manual & DBC Library
Vehicle & ECU Compatibility Matrix
Standalone Motorsport ECUs (Pre-Loaded Profiles)
Haltech: Elite Series, Nexus Series, Platinum (Haltech v2 protocol)
MaxxECU: Street, Sport, Race, Pro (v1.1, v1.2, and v1.3 stream definitions)
Ecumaster: EMU Black, EMU Classic, PMU
Link ECU: G4X, G4+
Megasquirt: MS3, MS2 (via CAN broadcast)
Custom Motorsport Systems: Syvecs, MoTeC, Emtron, Bosch via custom .dbc import
Factory OEM CAN-Bus Profiles (Plug-and-Play)
BMW: E46 (RPM, Coolant Temp, Wheel Speeds, Throttle)
VAG Group (PQ35 Platform): Golf Mk5, Golf Mk6, Scirocco, Audi TT, Seat Leon
Audi: S1 / EA888 Gen 3 (Simos 18 CAN stream)
More vehicle profiles continuously added via free Wi-Fi OTA firmware updates.
Universal OBD-II & UDS
Compatible with any vehicle equipped with ISO 15765-4 CAN OBD-II (11-bit & 29-bit, 250 kbps / 500 kbps) and ISO 14229 UDS (Service 0x22).
Features automated real-time True Boost calculation (MAP - BARO) and DTC fault code reading and clearing.
